Application
Thermon PETK circuit fabrication kits are required for use with all Thermon parallel heating cables connection kits. Kits for termination of SX cables include a power connection boot, end cap, RTV adhesive and a caution label. Kits for termination of HPT and FP cables also include tape strip and a distinct grommet.
SKU | P/N | Item | Cable type | Market |
---|---|---|---|---|
TMN.A30.001 | 23421 | PETK-1 | BSX, FLX, RSX, VSX, RGS, KSR | Europe |
TMN.A30.002 | 40-422.301.211.2 | PETK-1-OS | BSX, FLX, RSX, VSX, RGS, KSR | Europe |
TMN.A30.003 | 23420 | PETK-2 | KSX, HTSX | Europe |
TMN.A30.004 | 40-422.301.311.2 | PETK-2-OS | KSX, HTSX | Europe |
TMN.A30.005 | 40-422.301.511 | PETK-3 | FP, HPT (max 240°C) | Europe |
TMN.A30.006 | 40-422.301.513 | PETK-3-ZT | FP, HPT (max 240°C) | Europe |
TMN.A30.007 | 40-422.301.515 | PETK-3-ECM | FP, HPT (max 240°C) | Europe |
TMN.A30.008 | 38318 | PETK-4 | FP, HPT (max 260°C) | Europe |
TMN.A30.009 | 40-422.306.514 | PETK-4-ECM | HPT | Europe |
TMN.A30.010 | 40-422.301.621 | PETK-5 | TESH (2 sleeves + pins) | Europe |
TMN.A30.011 | 40-422.301.631 | PETK-10 CKTES-1 | TESH (cold lead connection kit) | Europe |
TMN.A30.012 | 40-422.301.632 | PETK-11 CKTES-2 | TESH (cold lead connection kit) | Europe |
TMN.A30.013 | 40-422.303.610 | PETK-7 | TESH (CETI 1525 + 3 m CL2.5) | Europe |
TMN.A29.018 | 23411 | PETK-1D | BSX, RSX, VSX-HT | Americas |
TMN.A29.019 | 23412 | PETK-2D | KSX, HTSX, USX | Americas |
TMN.A29.020 | 23413 | PETK-3D | HPT, FP | Americas |
Resources
Datasheet
English (Europe) datasheet
English (Americas) datasheet
Installation manual
English (Europe) installation instructions PETK-1, 2, 3
English (Europe) installation instructions PETK-4
English (Europe) installation instructions PETK-10, 11
English (Americas) installation instructions PETK-1, 2, 3
Certifications/Approvals
Ex EAC
FM Approved
CSA
Specifications
General
- Manufacturer
- Thermon
- Unit of measurement
- Piece
