E4X-1
Features
- Mechanical thermostat
- 2°C to 113°C
- 125/240/277/480 Vac
Application
The Thermon E4X-1 is designed for use as adjustable control thermostats for freeze protection and temperature maintenance applications requiring pipewall or tankwall sensing. A nonmetallic NEMA 4X enclosure combines thermostat functions and heating cable power connection into a single unit that can be installed directly onto a heattraced pipe (or to a nozzle protruding from a tank). The E4X1 provides watertight, dust tight and corrosion-resistant protection to the thermostat switch while permitting one heating cable to enter through the mounting expediter
The E4X-1 thermostat is approved for use in ordinary (nonclassified) locations.
| SKU | P/N | Item |
|---|---|---|
| TMN.A19.007 | E4X-1 | E4X-1 |
Resources
Datasheet
English (Americas) datasheet
Installation manual
English (Americas) installation instructions
Certifications/Approvals
FM Approvals
Ordinary Locations
Specifications
General
- Manufacturer
- Thermon
- Unit of measurement
- Piece
Ratings
- Voltage rating
- 125/240/277/480 Vac
- Switch rating
- 30/30/25/15 amps
- Switch type
- SPST
- Electrical connection
- Screw terminals on switch
- Adjustable control range
- 2°C to 113°C (35°F to 235°F)
- Maximum control differential
- 5°C
- Maximum bulb exposure temperature
- 149°C
- Bulb dimensions
- 6.4 x 162 mm
- Bulb material
- Nickel-plated copper
- Capillary length
- 1.7 m
- Capillary material
- Nickel-plated copper
