4X/7-350235JB
Features
- Mechanical thermostat
- 2°C to 113°C
- 125/240/277 Vac - 25 A
Application
The Thermon 4X/7-350235JB, equipped with a double-pole switch, is designed for use as an adjustable control thermostat for freeze protection and temperature maintenance applications requiring pipewall or tankwall sensing. The design of the thermostat permits its use as a junction box for connecting the heating cable to power by using the optional mounting kit (TM4X for ordinary locations or TM7 for Division 2 hazardous locations). The thermostat features an epoxy- coated cast aluminum NEMA 4X/NEMA 7 enclosure to provide watertight, dust tight, corrosionresistant and explosion proof protection to the thermostat switch.
The 4X/7-350235JB thermostat is approved for use in both ordinary (nonclassified) and hazardous (classified) locations.
| SKU | P/N | Item |
|---|---|---|
| TMN.A19.001 | 17350 | 4X/7-350235JB |
Resources
Datasheet
English (Americas) datasheet
Installation manual
English (Americas) installation instructions
Certifications/Approvals
FM Approvals
Ordinary Locations
Hazardous (Classified) Locations
Class I, Divisions 1 and 2, Groups B, C and D
Class II, Divisions 1 and 2, Groups F and G
Class III, Divisions 1 and 2
Specifications
General
- Manufacturer
- Thermon
- Unit of measurement
- Piece
Ratings
- Voltage rating
- 125/240/277 Vac
- Switch rating
- 25 amps
- Switch type
- DPST
- Electrical connection
- Screw terminals on switch
- Adjustable control range
- 2°C to 113°C
- Maximum control differential
- 5°C
- Maximum bulb exposure temperature
- 149°C
- Bulb dimensions
- 6.4 x 162 mm
- Bulb material
- Nickel-plated copper
- Capillary length
- 1.8 m
- Capillary material
- Nickel-plated copper
- Capillary armor
- Flexible stainless steel
